Name |
Portable Living Leaf Area Meter |
Model |
RC-70
|
Action |
Can
test the open door leaves area with not damage.easy to carries. Can
test many kinds of data, such as leaf area, average area, length of
leaf, width of leaf, thickness of leaf, perimeter
and ratio of Length to width.
|
Technical specification |
-Measuring range:leaf area, average area, length of leaf, width of
leaf, thickness of leaf, perimeter and ratio of Length to width.
Test
unit: Millimeter, square millimeter
-Precision: +2%
-Length: ¡Ü1000mm
-Width: ¡Ü160mm
-Thickness: ¡Ü8mm
-Stored datum:200Groups
-Battery:6v |
|
¡¡
|
Name |
Portable Living Leaf Area Meter |
Model |
RC-80 |
Action |
Can test the open door leaves area with not damage.easy to
carries. Can test many kinds of data, such as leaf area, average
area, length of leaf, width of leaf, thickness of leaf,
perimeter and ratio of Length to width.
|
Technical specification |
-Measuring range:leaf area, average area, length of leaf, width
of leaf, thickness of leaf, perimeter and ratio of Length to
width.
Test unit: Millimeter, square millimeter
-Precision: +2%
-Length: ¡Ü1000mm
-Width: ¡Ü160mm
-Thickness: ¡Ü8mm
-Stored datum:200Groups
-Battery:6v |
More |
RC-80 add RS-232 link with
computer by software, you can put the datum into computer. |
|
¡¡ |
Name |
Portable Living Leaf Area
Meter |
Model |
RC-90 |
Action
|
Can test the open door leaves area with not damage.easy
to carries. Can test many kinds of data, such as leaf
area, average area, length of leaf, width of leaf,
thickness of leaf, perimeter and
ratio of Length to width.
|
Technical specification |
-Measuring range:leaf area, average area, length of
leaf, width of leaf, thickness of leaf, perimeter and
ratio of Length to width.
Test unit: Millimeter, square millimeter
-Precision: +2%
-Length: ¡Ü1000mm
-Width: ¡Ü160mm
-Thickness: ¡Ü8mm
-Stored datum:200Groups
-Battery:6v |
RC-90 add GPS£¬can provide you
latitude and longitude data of
every measurement.
|
|
|
Camera type of Leaf area meter RC-80H
1.The
intelligent camera measurement system is composed of an image
acquisition device and an independent development software, using area
measurement algorithmthe of company accumulated over the years£¬according
to the feature extraction of blade profile, the physical transformation
of the image, the edge detection technology,can quickly get the image
and the measured leaf area, perimeter, wormhole number and other
parameters.Compared to the traditional leaf area, the measurement is
more rapid and convenient, the result is more objective , data diversity
and greatly reduce the error caused by human operation.
2.Main
technical parameters
Parameter measurement: leaf area, perimeter, maximum leaf length and
width, globose, shape coefficient, number of wormhole, wormhole area
Applicable scope: all kinds of common leaf containing complete or
wormhole
Measurement range: 1-600 square centimeter
Blade length: 0-297mm
Maximum leaf width: 0-210mm
Wormhole measuring range: not less than 0.5 square centimeters
Measurement accuracy: 2% (larger than 30cm2), 3% (less than 30cm2)
Host storage: more than 2000 groups
Stability: change within one year < + 2%
Response
time: 50ms
Application temperature: -80 C -30 C; relative humidity 0-100%
Host parameter:
Software system: Android4.2.2 or above
Size: 7 inch IPS capacitive touch screen
Memory: 32GB
Network support: WLAN (802.11 a/b/g/n) wireless network, Bluetooth 4
Interface: micro USB
Standard charging power supply: DC5V1A
Battery capacity: 3000mAH
Size: 9.3mm 187x111x weight: 266 G
3.software
introduction
1)¡¢After
testing a leaf, click on the real-time image can be returned to the
measurement interface, this time can be re placed on the another leaf or
second measurements of the same leaf.
2)¡¢Artificial aid£ºMainly used for complex blade edge or complex color
errors of the instrument for measuring the edge cases, using artificial
painted leaf edge, tell margin of instrument, which can makes the
measurement results more reliable. Usage: click on the "manual", began
to describe the margin, after describing the good, once again in the
same position Click to complete the auxiliary.
3)¡¢Parameter setting£ºMainly used for correction of measurement
accuracy.A known area of the blade or the color card into the
measurement, get the results of the parameters set, enter its true area,
click OK to exit.
4)¡¢Save / open image:Press the button to save the image, can save the
measured data and graphics , and then press the image to open the
function, can call the data has been saved.
5)¡¢Save data upload:File path, click on the "file management",
"pictures", "leaf area detection" can see graphics which you saved, the
corresponding data will in accordance with the time to sort records in "result.csv"
, you can use plate installed Baidu cloud software uploaded to the PC
side(Baidu accounts need to be registered on their own). |
