surface profile gauge

surface-profile-gauge-srt6223 china



surface profile gauge Item No. : SRT-6223

specially used to take accurate measurement of the peak to valley height of the surface profile of the surface profile of blast cleaned surfaces.


display: 4 digits. LCD

Range: 0um to 800um (0mils to 30mils)

Accuracy: +5% or +5( whichever is the greater)

resolution: 1um (0.1mils)

Metric and Imperial switchable

PC interface: RS232C

Measurement speed: >30readings per minute

weight: 280g

dimensions: 162x65x28mm(6.4x2.6x1.1 inch)

operating temperature: 0-50 , 80% RH

Case: high impact ABS

Batteries: 4x1.5v (AAA) Battery

standard accessories included:

carrying case: 1 pc

operation manual 1 pc

optional accessory:

cable and software for RS232C
